Amazing Microelectronic is a leading provider of high-performance semiconductor solutions, specializing in strong and efficient communication technology. Their RS-485 transceivers, the AZRS6534 and AZRS9894P, are engineered to enhance data transmission with advanced protection, reliability, and efficiency.

AZRS6534: High-Speed and Reliable Half-Duplex Transceiver

The AZRS6534 stands out with its fail-safe receiver, ensuring a logic-high output when receiver inputs are open, shorted, or idle. This feature eliminates the need for external pull-up and pull-down resistors, simplifying system design and improving reliability.

A key advantage of the AZRS6534 is its hot-swap glitch-free protection, which ensures high-impedance states for the transmitter and receiver during power-up. This reduces inrush currents, prevents damage, and enhances power efficiency.

Features:

• Thermal shutdown protection activates at 150°C, protecting the device from overheating.

• Current-limiting protection prevents damage due to system faults.

• High immunity to latch-up (±400mA), enhancing overall system reliability.

• ESD protection with integrated TVS diodes, ensuring durability against high-energy transients.

• Supporting a high-speed data rate of 8Mbps, the AZRS6534 is ideal for industrial automation, process control, and communication networks.

AZRS9894P: Advanced Protection with High Noise Immunity

The AZRS9894P offers enhanced ESD protection, with ±8kV IEC61000-4-2 contact protection on bus pins and overall chip protection up to HBM ±8kV, MM ±600V, and CDM ±2kV. This makes it a top choice for environments prone to electrostatic discharge and electrical noise.

Features:

• Hot-swap glitch-free protection, preventing system disruptions during power-up.

• ±70V fault protection, ensuring bus integrity in extreme conditions.

• True fail-safe receiver, maintaining a high output even in open or idle states.

• Current-limited transmitter and thermal shutdown, preventing damage under fault conditions.

Much like the AZRS6534, the AZRS9894P operates as a half-duplex RS-485 transceiver, supporting 1/8 unit load capability, allowing up to 256 devices to share the RS-485 bus.

Applications:

• Industrial Control

• Telecom Equipment

• Security System

• Building Automation Networks

By integrating fail-safe mechanisms, hot-swap capabilities, and superior fault protection, Amazing Microelectronic’s AZRS6534 and AZRS9894P redefine RS-485 communication with superior reliability and efficiency.
